ASROCK FM2A55M-VG3 Quick Installation Guide

33
ASRock FM2A55M-VG3 Motherboard
簡體中文
主板規格
架构 - Micro ATX 規格
- 全固態電容設計
處理器 - FM2 插槽支持 100W 處理器
- 支持 AMD Cool
‘
n
’
Quiet
™
冷靜技術
- UMI-Link GEN2
芯片組 - AMD A55 FCH (Hudson-D2)
系統內存 - 支持雙通道 DDR3 內存技術
- 配備 2 個 DDR3 DIMM 插槽
- 支持 DDR3 1866/1600/1333/1066 non-ECC、un-buffered 內存
- 最高支持 32GB 系統容量
- 支持 Intel
®
Extreme Memory Profile(XMP)1.3/1.2
- 支持 AMD Memory Profile(AMP)
擴展插槽 - 1 x PCI Express 2.0 x16 插槽 (PCIE1: x16 模式 )
- 1 x PCI 插槽
- 支持 AMD 雙顯卡技術
板載顯卡 - AMD Radeon HD 7000 顯卡
- DirectX 11、Pixel Shader 5.0 技術
- 最大共享內存 2GB
- 支持 D-Sub, 最高分辨率達 1920x1600 @ 60Hz
- 支持 AMD Steady Video
TM
2.0: 最新視頻后處理能力，可為家
庭 / 在線視頻提供自動降低抖動的功能
音效 - 5.1 聲道高保真音頻 (Realtek ALC662 音頻編解碼器 )
板載 LAN 功能 - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- 支持網路線偵測功能
- 支持 Energy Efficient Ethernet 802.3az
- 支持 PXE
Rear Panel I/O I/O 界面
( 后面板輸入 / - 1 個 PS/2 鼠標接口
輸出接口 ) - 1 個 PS/2 鍵盤接口
- 1 個 VGA 接口
- 4 個可直接使用的 USB 2.0 接口
- 1 個 RJ-45 局域网接口與 LED 指示燈 (ACT/LINK LED 和
SPEED LED)
- 高保真音頻插孔：音頻輸入 / 前置喇叭 / 麥克風

ASROCK FM2A55M-VG3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Processor socket	Socket FM2
Processor manufacturer	AMD
Compatible processor series	AMD A
Processor thermal power (max)	100 W
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Certification	- FCC, CE, WHQL - ErP/EuP
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55 FCH
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA II
Graphics card	Radeon HD 7000
DirectX version	11
Maximum resolution	1920 x 1600 pixels
Maximum graphics card memory	2048 MB
BIOS type	UEFI AMI
ACPI version	1.1

Weight and Dimensions

Width	- mm
