FM2A58M-HD+
11
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
5 ATX Power Connector (ATXPWR1)
6 Chassis Speaker Header (SPEAKER1)
7 System Panel Header (PANEL1)
8 SATA 2 Connector (SATA _1)
9 SATA 2 Connector (SATA _ 2)
10 TPM Header (TPMS1)
11 Chassis Fan Connector (CHA_FAN1)
12 SATA 2 Connector (SATA _4)
13 SATA2 Connector (SATA _3)
14 SATA 2 Connector (SATA _6)
15 SATA 2 Connector (SATA _5)
16 USB 2.0 Header (USB6_7)
17 USB 2.0 Header (USB8_9)
18 Print Port Header (LPT1)
19 COM Port Header (COM1)
20 Front Panel Audio Header (HD_AUDIO1)
21 Clear CMOS Jumper (CLRCMOS1)
22 Chassis Intrusion Header (CI1)
