Storage
•
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
Connec-
tor
•
1 x Print Port Header
•
1 x COM Port Header
•
1 x Chassis Intrusion Header
•
1 x TPM Header
•
1 x CPU Fan Connector (4-pin)
•
1 x Chassis Fan Connector (4-pin)
•
1 x Power Fan Connector (3-pin)
•
1 x 24 pin ATX Power Connector
•
1 x 4 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
(Supports ESD Protection (ASRock Full Spike Protec-
tion))
•
1 x USB 3.0 Header by ASMedia ASM1042A (Supports
2 USB 3.0 ports) (Supports ESD Protection (ASRock
Full Spike Protection))
BIOS
Feature
•
64Mb AMI UEFI Legal BIOS with GUI support
•
Supports “Plug and Play”
•
ACPI 1.1 Compliant wake up events
•
Supports jumperfree
•
SMBIOS 2.3.1 support
•
DRAM, CPU Voltage multi-adjustment
Hardware
Monitor
•
CPU temperature sensing
•
Chassis temperature sensing
•
CPU Fan Tachometer
•
Chassis Fan Tachometer
•
CPU/Chassis Quiet Fan
•
CPU/Chassis Fan multi-speed control
•
CASE OPEN detection
•
Voltage monitoring: +12V, +5V, +3.3V, Vcore
