ASROCK FM2A75M-DGS R2.0 Quick Installation Guide

8
ASRock FM2A75M-DGS R2.0 Motherboard
English
1.3 Pin Header Easy Installation Guide
ASRock motherboard is equipped with pin headers with obvious colors which indi-
cate you to recognize the crucial headers more easily. Please refer to below illustra-
tions for the pin denition of onboard headers. If you want to have more information
about the usage of these headers, please refer to “Jumpers Setup“ and “Onboard
Headers and Connectors“ for details.
Front Panel Audio Header
System Panel Header
USB 2.0 Header
Chassis Speaker Header
USB 3.0 Header
IntA_P_D+
IntA_P_D-
GND
IntA_P_SSTX+
IntA_P_SSTX-
GND
IntA_P_SSRX+
ntA_P_SSRX-
Vbus
IntA_P_SSTX+
IntA_P_SSTX-
GND
ntA_P_SSRX+
1
ID
IntA_P_D+
IntA_P_D-
GND
I
Vbus
I
IntA_P_SSRX-
