12
No. Description
1 Power Fan Connector (PWR_FAN1)
2 ATX12VPowerConnector(ATX12V1)
3 CPU Fan Connector (CPU_FAN1)
4 CPU Fan Connector (CPU_FAN2)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
7 ATX Power Connector (ATXPWR1)
8 USB 3.0 Header (USB3_9_10)
9 SATA3 Connector (SATA3_4)
10 SATA3 Connector (SATA3_2)
11 SATA3 Connector (SATA3_1)
12 SATA3 Connector (SATA3_3)
13 SATA3 Connector (SATA3_5)
14 System Panel Header (PANEL1)
15 Chassis Speaker Header (SPEAKER1)
16 Chassis Fan Connector (CHA_FAN1)
17 Infrared Module Header (IR1)
18 Power LED Header (PLED1)
19 Clear CMOS Jumper (CLRCMOS1)
20 USB 2.0 Header (USB_13_14)
21 USB 2.0 Header (USB_11_12)
22 COM Port Header (COM1)
23 TPM Header (TPMS1)
24 Chassis Intrusion Header (CI1)
25 Front Panel Audio Header (HD_AUDIO1)
26 Chassis Fan Connector (CHA_FAN2)
27 Chassis Fan Connector (CHA_FAN3)
