English
2
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Chassis/Waterpump Fan Connector (CHA_FAN1/WP)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5 ATX Power Connector (ATXPWR1)
6 Chassis Fan Connector (CHA_FAN2)
7 USB 3.1 Gen1 Header (USB3_6_7)
8 SATA3 Connector (SATA3_1)
9 SATA3 Connector (SATA3_0)
10 SATA3 Connector (SATA3_3)
11 SATA3 Connector (SATA3_2)
12 System Panel Header (PANEL1)
13 USB 2.0 Header (USB_3_4)
14 Clear CMOS Jumper (CLRMOS1)
15 Chassis Intrusion Header (CI1)
16 SATA3 Connector (SATA3_4)
17 SATA3 Connector (SATA3_5)
18 Chassis Speaker Header (SPEAKER1)
19 TPM Header (TPMS1)
20 Front Panel Audio Header (HD_AUDIO1)
