ASROCK H410M-ITX/ac User Manual

57
H410M-IT X/ac
Bahasa Indonesia
Penyimpanan
•
4 x Konektor SATA3 6,0 Gb/s, mendukung NCQ, AHCI, dan
Hot Plug
* Jika M2_1 digunakan perangkat SATA tipe M.2, maka SATA3_0
akan dinonaktian.
•
1 x Soket Ultra M.2 (M2_1), mendukung jenis modul 2260/2280
M.2 SATA3 6,0 Gb/s dan modul M.2 PCI Express hingga Gen3
x4 (32 Gb/s)**
* Mendukung SSD NVMe sebagai disk boot
* Mendukung Kit U.2 ASRock
Konektor
•
1 x Header Chassis Intrusion
•
1 x Header LED RGB
* Mendukung total Strip LED hingga 12V/3A, 36W
•
1 x Addressable LED Header
* Mendukung total Strip LED hingga 5V/3A, 15W
•
1 x Konektor Kipas CPU (4-pin)
* Konektor Kipas CPU mendukung kipas CPU dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis (4-pin)
* Konektor Kipas Sasis mendukung kipas sasis dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis/Pompa Air (4-pin) (Kontrol
Kecepatan Kipas Pintar)
* Chassis/Kipas Pompa Air mendukung kipas berpendingin air
dengan daya kipas maksimum 2A (24W).
* CHA_FAN1/WP dapat mendeteksi otomatis jika kipas 3-pin atau
4-pin sedang digunakan.
•
1 x Konektor Daya ATX 24 pin
•
1 x Konektor Daya 8 pin 12V
•
1 x Konektor Audio Panel Depan
•
1 x Header USB 2.0 (Mendukung 2 port USB 2.0) (Mendukung
Perlindungan dari ESD)
•
1 x Header USB 3.2 Gen1 (Mendukung 2 port USB 3.2 Gen1)
(Mendukung Perlindungan dari ESD)
OS
•
Microso® Windows® 10 64-bit

ASROCK H410M-ITX/ac Specifications

General

Audio chip	Realtek ALC887
Component for	-
Motherboard chipset	Intel H410
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 2933 MHz
Processor socket	LGA 1200 (Socket H5)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III, Ultra M.2
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
OpenGL version	4.5
DirectX version	12.0
USB connector type	USB Type-A, USB Type-C
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Number of SATA III connectors	4

Weight and Dimensions

Width	170 mm
