ASROCK H61MV-ITX Quick Installation Guide

21
ASRock H61MV-ITX Motherboard
Specifi che
Piattaforma - Mini-ITX Form Factor
- Design condensatore compatto
Processore - Supporta Intel
®
Core
TM
i7 / i5 / i3 di 3a e 2a generazione in un
pacchetto LGA1155
- Supporto della tecnologia Intel
®
Turbo Boost 2.0
- Supporta CPU unlocked serie K
Chipset - Intel
®
H61
- Supporta tecnologia Intel
®
Rapid Start Technology e Smart
Connect Technology
Memoria - Supporto tecnologia Dual Channel Memory
- 2 x slot DDR3 DIMM
- Supporto DDR3 1600/1333/1066 non-ECC, momoria senza
buffer (DDR3 1600 con CPU Intel
®
Ivy Bridge, DDR3 1333 con
CPU Intel
®
Sandy Bridge)
- Capacità massima della memoria di sistema: 16GB
- Supporto di Intel
®
XMP (Extreme Memory Profi le)1.3/1.2 con
CPU Intel
®
Ivy Bridge
Slot di - 1 x Alloggi PCI Express 3.0 x16 (PCIE1 a modalità x16)
espansione * PCIE 3.0 è supportato soltanto con la CPU Intel
®
Ivy Bridge.
Con la CPU Intel
®
Sandy Bridge, supporta solamente PCIE
2.0.
VGA su scheda * Le uscite Intel
®
HD Graphics Built-in Visuals e VGA possono
essere supportate solo con processori dotati di GPU
integrata.
- Supporta Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick Sync
Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD Technology,
Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000 con CPU Intel
®
Ivy Bridge
- Supporta Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick Sync
Video, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD Technology,
Intel
®
HD Graphics 2000/3000, Intel
®
Advanced Vector
Extensions (AVX) con CPU Intel
®
Sandy Bridge
- Pixel Shader 5.0, DirectX 11 con CPU Intel
®
Ivy Bridge, Pixel
Shader 4.1, DirectX 10.1 con CPU Intel
®
Sandy Bridge
- Memoria massima condivisa 1760MB con CPU Intel
®
Ivy Bridge. Memoria massima condivisa 1759MB con CPU
Intel
®
Sandy Bridge.
- Uscita VGA Doppia: supporto porte HDMI e D-Sub tramite
verifi catore display indipendente
Italiano

ASROCK H61MV-ITX Specifications

General

Non-ECC	Yes
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	8GB
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-2xxx, i3-3xxx, i5-2xxx, i5-3xxx, i7-2xxx, i7-3xxx
Number of SATA connectors	-
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	3.0
Cables included	SATA
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit

Weight and Dimensions

Width	- mm
