12
16. ASRock Crashless BIOS allows users to update their BIOS without fear
of failing. If power loss occurs during the BIOS update process, ASRock
Crashless BIOS will automatically nish the BIOS update procedure after
regaining power. Please note that BIOS les need to be placed in the root
directory of your USB disk. Only USB2.0 ports support this feature.
17. ASRock On/Off Play Technology allows users to enjoy the great audio
experience from the portable audio devices, such like MP3 player or
mobile phone to your PC, even when the PC is turned off (or in ACPI S5
mode)! This motherboard also provides a free 3.5mm audio cable (op-
tional) that ensures users the most convenient computing environment.
18. While CPU overheat is detected, the system will automatically shutdown.
Before you resume the system, please check if the CPU fan on the moth-
erboard functions properly and unplug the power cord, then plug it back
again. To improve heat dissipation, remember to spray thermal grease
between the CPU and the heatsink when you install the PC system.
19. Combo Cooler Option (C.C.O.) provides the exible option to adopt three
different CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156.
Please be noticed that not all the 775 and 1156 CPU Fan can be used.
20. ASRock XFast RAM is not supported by Microsoft
®
Windows
®
XP / XP
64-bit. Intel
®
Smart Connect Technology and Intel
®
USB 3.0 ports are not
supported by Microsoft
®
Windows
®
Vista
TM
/ Vista
TM
64-bit / XP / XP 64-
bit.
21. EuP stands for Energy Using Product, was a provision regulated by the
European Union to define the power consumption for the completed
system. According to EuP, the total AC power of the completed system
should be under 1.00W in off mode condition. To meet EuP standards,
an EuP ready motherboard and an EuP ready power supply are required.
According to Intel’s suggestion, the EuP ready power supply must meet
the standard of 5v, and the standby power ef ciency should be higher
than 50% under 100 mA current consumption. For EuP ready power sup-
ply selection, we recommend you to check with the power supply manu-
facturer for more details.

Table of Contents

Other manuals for ASROCK H77 Pro4-M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK H77 Pro4-M and is the answer not in the manual?

ASROCK H77 Pro4-M Specifications

General IconGeneral
ECCNo
Non-ECCYes
Memory voltage1.5 V
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR3-SDRAM
Maximum internal memory32 GB
Supported memory clock speeds1066, 1333, 1600 MHz
Supported memory module capacities16GB, 1GB, 2GB, 4GB, 8GB
System bus rate5 GT/s
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors1
USB 2.0 connectors3
Number of Parallel ATA connectors0
HDMI version1.4a
Headphone outputs5
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Audio chipRealtek ALC892
Cooling typePassive
CertificationFCC, CE, WHQL, ErP/EuP Ready
Component forPC
Power source typeATX
Motherboard chipsetIntel H77
PC health monitoringCPU, FAN, Temperature
Audio output channels7.1 channels
Motherboard form factormicro ATX
Compatible operating systemsWindows 7, Vista, XP 32/64-bit
RAID levels0, 1, 5, 10
Supported storage drive interfacesSATA II, SATA III
Cables includedSATA
Graphics cardHD Graphics
OpenGL version3.2
DirectX version11
Maximum resolution2048 x 1536 pixels
Maximum graphics card memory1760 MB
Parallel processing technology support2-Way CrossFireX
PCI Express slots version2.0, 3.0
PCI Express configurations1x4, 1x16
Controller 2nd interface typeASMedia ASM1061
LAN controllerRealtek RTL8111E
Wi-Fi standardsNot supported
Networking featuresGigabit LAN
Ethernet interface typeGigabit Ethernet
BIOS typeEFI AMI
ACPI version1.1
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Width244 mm
