ASROCK N3700-ITX - Page 4

English
2
No. Description
1 CPU Fan Connector (CPU_FAN1)
2 2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_B1)
3 ATX Power Connector (ATXPWR1)
4 USB 3.0 Header (USB3_3_4)
5 USB 2.0 Header (USB_5_6)
6 Chassis Fan Connector (CHA_FAN1)
7 USB 2.0 Header (USB_3_4)
8 SATA3 Connector (SATA3_1)
9 SATA3 Connector (SATA3_2)
10 Chassis Speaker Header (SPEAKER1)
11 System Panel Header (PANEL1)
12 Clear CMOS Jumper (CLRMOS1)
13 COM Port Header (COM1)
14 SATA3 Connector (SATA3_A2)
15 SATA3 Connector (SATA3_A1)
16 TPM Header (TPMS1)
17 Front Panel Audio Header (HD_AUDIO1)
