71
Español
Q1900TM-ITX
Base de conexiones de
pines de entrada/salida
digital
(JGPIO1 de 10 pines)
(consulte la pág. 1, nº 23)
PIN
Nombre
de señal
PIN
Nombre de
señal
6 GND 5
JGPIOPWR
(usar JGPIO_
PWR1 para
congurar)
4 GPIO4 3 GPIO3
2 GPIO2 1 GPIO1
1
