ASROCK QC5000-ITXQC5000-ITX/PH Manual

3
English
QC5000-ITX/WiFi
QC5000-ITX
I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB01) 9 Microphone (Pink)
2 D-Sub Port 10 Optical SPDIF Out Port
3 DisplayPort 1.2* 11 USB 3.0 Ports (USB3_4_5)
4 LAN RJ-45 Port** 12 HDMI Port*
5 Central / Bass (Orange) 13 DVI-D Port
6 Rear Speaker (Black) 14 USB 3.0 Ports (USB3_0_1)
7 Line In (Light Blue) 15 PS/2 Mouse/Keyboard Port
8 Front Speaker (Lime)*** 16
Antenna Port (for QC5000-ITX/
WiFi only)
1 4
1115 910
6
5
8
7
1213
2 3
16 14

ASROCK QC5000-ITXQC5000-ITX/PH Specifications

General

Brand	ASROCK
Model	QC5000-ITXQC5000-ITX/PH
Category	Motherboard
Language	English
