ASROCK X299E-ITX/ac Manual

22
English
Power LED and Speaker
Header
(7-pin SPK_PLED1)
(see p.1, No. 10)
Please connect the
chassis power LED and
the chassis speaker to this
header.
Serial ATA3 Connectors
(SATA3_2_3:
see p.3, No. 21)
(SATA3_4_5:
see p.3, No. 22)
(SATA3_6_7:
see p.3, No. 23)
ese six SATA3
connectors support SATA
data cables for internal
storage devices with up to
6.0 Gb/s data transfer rate.
USB 2.0 Header
(9-pin USB_5_6)
(see p.3, No. 20)
is USB 2.0 header can
support two ports.
USB 3.1 Gen1 Header
(19-pin USB_7_8)
(see p.3, No. 24)
is USB 3.1 Gen1 header
can support two ports.
Front Panel Audio Header
(9-pin HD_AUDIO1)
(see p.1, No. 14)
is header is for
connecting audio devices
to the front audio panel.
J_SENSE
OUT2_L
1
MIC_RET
PRESENCE#
GND
OUT2_R
MIC2_R
MIC2_L
OUT_RET
SATA3_6_7
SATA3_4_5
SATA3_2_3
DUMMY
GND GND
P+
P-
P+
P-
USB_PWR
USB_PWR
1
1
ID
In tA_P _D+
In tA_P _D-
GN D
In tA_P _SST X+
In tA_P _SST X-
GN D
In tA_P _SSR X+
Vb us
In tA_P _D+
In tA_P _D-
GN D
In tA_P _SST X+
In tA_P _SST X-
GN D
In tA_P _SSR X+
In tA_P _SSR X-
Vb us
In tA_P _SSR X-
