No. Description
1 Chassis Fan / Waterpump Fan Connector (CHA_FAN1/W_PUMP)
2 Virtual RAID On CPU Header (VROC1)
3 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1)
4 RGB LED Header (RGB_LED1)
5 System Panel Header (PANEL1)
6 ATX 12V Power Connector (ATX12V1)
7 Front Socket (FRONTI_IO1)
8 CPU Fan Connector (CPU_FAN1)
9 CPU Fan / Waterpump Fan Connector (CPU_OPT/W_PUMP)
10 Power LED and Speaker Header (SPK_PLED1)
11 ATX Power Connector (ATXPWR1)
12 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_C1, DDR4_D1)
13 Rear Button Switch (REAR_BTN_SEL1)
14 Front Panel Audio Header (HD_AUDIO1)
15 Rear Socket (REAR_IO)
16 TPM Header (TPMS1)
17 Ultra M.2 Socket (M2_3)
18 Ultra M.2 Socket (M2_2)
19 Ultra M.2 Socket (M2_1)
20 USB 2.0 Header (USB_5_6)
21 SATA3 Connectors (SATA3_2_3)
22 SATA3 Connectors (SATA3_4_5)
23 SATA3 Connectors (SATA3_6_7)
24 USB 3.1 Gen1 Header (USB_7_8)
