ASROCK Z490M-ITX/ac Manual

166
Bahasa Indonesia
Penyimpanan
•
4 x Konektor SATA3 6,0 Gb/s, mendukung RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 17),
NCQ, AHCI, dan Hot Plug*
•
1 x Soket Ultra M.2 (M2_1), mendukung jenis modul 2260/2280
M.2 SATA3 6,0 Gb/s dan modul M.2 PCI Express hingga Gen3 x4
(32 Gb/s)*
•
1 x Soket Ultra M.2 (M2_2), mendukung jenis modul 2280 M.2
PCI Express hingga Gen3 x4 (32 Gb/s)**
** Mendukung Intel® Optane
TM
Technology
** Mendukung SSD NVMe sebagai disk boot
** Mendukung Kit ASRock U.2
Konektor
•
1 x Header LED RGB
* Mendukung total Strip LED hingga 12V/3A, 36W
•
1 x Addressable LED Header
* Mendukung total Strip LED hingga 5V/3A, 15W
•
1 x Konektor Kipas CPU (4-pin)
* Konektor Kipas CPU mendukung kipas CPU dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis (4-pin)
* Konektor Kipas Sasis mendukung kipas sasis dengan daya kipas
maksimum 1A (12W).
•
1 x Konektor Kipas Chassis/Pompa Air (4-pin) (Kontrol
Kecepatan Kipas Pintar)
* Chassis/Kipas Pompa Air mendukung kipas berpendingin air
dengan daya kipas maksimum 2A (24W).
* CHA_FAN1/WP dapat mendeteksi otomatis jika kipas 3-pin atau
4-pin sedang digunakan.
•
1 x Konektor Daya ATX 24 pin
•
1 x Konektor Daya 8 pin 12V
•
1 x Konektor Audio Panel Depan
•
1 x Header USB 2.0 (Mendukung 2 port USB 2.0) (Mendukung
Perlindungan dari ESD)
•
1 x Header USB 3.2 Gen1 (Mendukung 2 port USB 3.2 Gen1)
(Mendukung Perlindungan dari ESD)
Fitur BIOS
•
AMI UEFI Legal BIOS dengan dukungan GUI multibahasa
•
ACPI 6.0 Kompatibel dengan aktivitas pengaktifan
•
Dukungan SMBIOS 2.7
•
Multipengatur Tegangan CPU, DRAM, PCH 1,05V, VCCIO,
VCCSA

ASROCK Z490M-ITX/ac Specifications

General

HDMI version	1.4
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
RGB LED pin header	Yes
LAN controller	Dragon RTL8125BG, Intel I219-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	2.5 Gigabit Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC1200
Component for	PC
Motherboard chipset	Intel Z490
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10
OpenGL version	4.5
DirectX version	12.0
Maximum resolution	4096 x 2304 pixels
Parallel processing technology support	Not supported
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 2933, 3200, 3600, 3733, 3800, 3866, 4000, 4133, 4266, 4333, 4400 MHz
Cables included	SATA
BIOS type	UEFI AMI
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium

Weight and Dimensions

Width	170 mm
