Page #53 background imageLoading...
Page #53 background image
49
Z490M-ITX/ac
Français
Graphiques
•
La technologie Intel® UHD Graphics Built-in Visuals et les sorties
VGA sont uniquement prises en charge par les processeurs
intégrant un contrôleur graphique.
•
Codecs d’accélération matérielle : AVC/H.264, HEVC/H.265 8bit,
HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2, MJPEG,
VC-1
* VP9 10 bits et VC-1 sont uniquement destinés au décodage.
* Lencodage VP8 et VP9 nest pas pris en charge par le système
d’exploitation Windows.
•
Graphismes, multimédia et calcul : Microso DirectX 12,
OpenGL 4.5, Intel® Built In Visuals, Intel® Quick Sync Video,
Hybrid Graphics / Basculement des graphismes, OpenCL 2.1
•
Achage et sécurité du contenu : Rec. 2020 (large gamme de
couleurs), Microso PlayReady 3.0, protection de contenu Intel®
SGX, disque Blu-ray UHD/HDR
•
Double sortie graphique: Prend en charge les ports HDMI et
DisplayPort 1.4 via contrôleurs dachage indépendants
•
Prend en charge la technologie HDMI 1.4 avec résolution
maximale de 4K x 2K (4096x2160) @ 30Hz
•
Prend en charge la technologie DisplayPort 1.4 avec résolution
maximale de 4K x 2K (4096x2304) @ 60Hz
•
Prend en charge les technologies Auto Lip Sync, Deep Color
(12bpc), xvYCC et HBR (High Bit Rate Audio) avec port HDMI 1.4
(un écran compatible HDMI est requis)
•
Prend en charge HDCP 2.3 via ports HDMI 1.4 et DisplayPort 1.4
•
Prend en charge la lecture 4K Ultra HD (UHD) avec les ports
HDMI 1.4 et DisplayPort 1.4
Audio
•
Audio 7.1 CH HD avec protection du contenu (codec audio
Realtek ALC1200)
•
Compatible audio Blu-ray Premium
•
Prend en charge la protection contre les surtensions
•
Blindage isolant PCB
•
Couches de PCB individuelles pour canal audio D/G
•
Audio Nahimic

Other manuals for ASROCK Z490M-ITX/ac

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK Z490M-ITX/ac and is the answer not in the manual?

ASROCK Z490M-ITX/ac Specifications

General IconGeneral
HDMI version1.4
PS/2 ports quantity1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
RGB LED pin headerYes
LAN controllerDragon RTL8125BG, Intel I219-V
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version4.2
Ethernet interface type2.5 Gigabit Ethernet, Gigabit Ethernet
Audio chipRealtek ALC1200
Component forPC
Motherboard chipsetIntel Z490
PC health monitoringFAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factormini ITX
Motherboard chipset familyIntel
Windows operating systems supportedWindows 10
OpenGL version4.5
DirectX version12.0
Maximum resolution4096 x 2304 pixels
Parallel processing technology supportNot supported
Memory channelsDual-channel
Memory slots typeDIMM
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds2133, 2400, 2666, 2800, 2933, 3200, 3600, 3733, 3800, 3866, 4000, 4133, 4266, 4333, 4400 MHz
Cables includedSATA
BIOS typeUEFI AMI
BIOS memory size128 Mbit
System Management BIOS (SMBIOS) version2.7
RAID levels0, 1, 5, 10
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSATA III
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Weight and Dimensions IconWeight and Dimensions
Width170 mm
