PN# 500-18300

Page 10 Rev. D, 08/11

TEMPLATE FOR CUTTING OUT ANSI 2 ¾” STRIKE PREPARATION AND INSTALLING UNLATCH ON

WOODEN FRAME

DOTTED LINE SHOWS AREA TO

CHISEL OUT 1 3/4" DEEP FOR

INSTALLATION IN WOOD FRAME

4 7/8"

1 1/4"

4 1/8"

CENTER LINE

HORIZONTAL

ALIGNMENT

ARROWS (SEE

FIG. 3)
