Associated Research OMNIA II 8207 User Manual

241
Range 5
0.0uA ~ 504uA, frequency 15Hz
- 1MHz
Resolution
1uA
Additional Error
15Hz < f < 100KHz : add ±(2% of
reading + 0.2% of range) to base
accuracy
100KHz < f < 1MHZ : add ±(2% of
reading + 0.5% of range) to base
accuracy
Range 6
0.0uA ~ 600uA, frequency DC –
100KHz
Resolution
1uA
Additional Error
15Hz < f < 100KHz : add ±(2% of
reading + 0.2% of range) to base
accuracy
DISPLAY AUTO RANGE
Touch Voltage Display (RMS)
(AC+DC)
Range 1
0.0mV ~ 32.0mV, frequency DC,
15Hz – 1MHz
Resolution
0.1mV
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10.0mV - 999.9mV)
Range 2
28.0mV ~ 130.0mV, frequency DC,
15Hz - 1MHz
Resolution
0.1mV
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10.0mV - 999.9mV)
Range 3
120.0mV ~ 525.0mV, frequency DC,
15Hz - 1MHz
Resolution
0.1mV
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10.0mV - 999.9mV)
Range 4
400mV ~ 999.9mV,1000mV ~
2100mV, frequency DC, 15Hz - 1MHz
Resolution
0.1mV, 1mV
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10mV - 8500mV)
Range 5
1800mV ~ 8400mV, frequency DC,
15Hz - 1MHz
Resolution
1mV
