ASTEC 40 Series - 200-Hour Lubrication; 2500-Hour Lubrication

Lubrication
IB-2003
S
eries 40 Trans
fl
ite -
S
tationary
C
onveyor
53
1. Clean and coat take up
screw rods with NLGI2
grease.
2. Repeat procedure for
opposite side.
Take-up Screw Rod
(200 hours)
Gear Reducers
(2500 hours or 6 months)
The oil in the gear reducers
should be changed every 2500
hours or six months - whichever
comes fi rst. To change the oil,
use the following procedure.
1. Drain oil from the gear
reducer.
2. Flush with kerosene.
3. Clean magnetic drain plug.
Refer to page 52 for gear
reducer positions.
2.7 / 2.5
16.1 / 15.3
Approximate volume of Oil to Fill Reducer to Oil Level Plug
Reducer Size
Position A Position B Position C Position D
TA3203H
TA4207H
Single
Double
Single
Double
Quart / Liters
Quart / Liters
Quart / Liters Quart / Liters
2.8 / 2.7
2.8 / 2.7
1.6 / 1.6
1.5 / 1.4
1.8 / 1.7
1.7 / 1.6
4.1 / 3.9
4.0 / 3.8
4.4 / 4.2
4.4 / 4.2
2.6 / 2.5
2.5 / 2.4
2.9 / 2.8
2.8 / 2.6
7.4 / 7.0
7.3 / 6.9
TA1107H
Single
Double
Single
Double
1.3 / 1.3
1.3 / 1.3
.7 / .7
.7 / .7
.7 / .6
.6 / .6
1.7 / 1.6
1.7 / 1.6
2.1 / 2.0
2.1 / 2.0
1.2 / 1.2
1.1 / 1.1
1.0 / 1.0
1.0 / 1.0 2.6 / 2.5
TA2115H
TA5215H Single
Double
7.4 / 7.0
7.4 / 7.0
4.9 / 4.7
4.7 / 4.4
5.8 / 5.5
5.5 / 5.2
13.2 / 12.5
12.9 / 12.2
TA7315H
TA8407H
Single
Double
Single
Double
8.4 / 8.0
8.4 / 8.0
11.8 / 11.1
10.8 / 10.3
13.9 / 13.2
13.2 / 12.5
22.5 / 21.3
22.0 / 20.9
N/A
7.7 / 7.3
N/A
11.7 / 11.1
N/A
13.7 / 12.9
N/A
25.1 / 23.8
Single
Double
8.8 / 8.4
8.8 / 8.4
5.8 / 5.5
5.5 / 5.2
6.6 / 6.2
6.2 / 5.9 15.8 / 15.0
TA6307H
TA9415H Single
Double
N/A
17.0 / 16.1
N/A
16.8 / 15.9
N/A
18.1 / 17.1
N/A
33.2 / 31.4
4. Refill gear reducer to
proper level with new
lubricant.
