Astec Mobile Screens Parts 43 KDS 710
710
KDS
ITEM QTY PART NUMBER DESCRIPTION
1 1 C03629 Hydraulic Motor
2 1 C04816 Coupling Sleeve
3 1 C04817 Bushing
4 1 C04819 Bushing
5 2 C04820 Coupling Flange
6 2 C05640 Bearing
7 4 C05641 Springs, Coil
8 8 C05642 Spring Retainer
9 2 C05643 Bearing Retainer Ring Gasket
10 2 H00011 Bolt
11 8 H00026 Bolt
12 80 H00028 Bolt
13 24 H00044 Bolt
14 11 H00048 Flatwasher
15 80 H00051 Flat Washer
16 11 H00060 Lockwasher
17 2 H00061 Lockwasher
18 8 H00063 Lockwasher
19 11 H00066 Nut
20 2 H00067 Nut
21 36 H00068 Nut
22 8 H00069 Nut
23 80 H00077 Nylock
24 24 H00084 Nut
25 4 H00237 Screw
26 11 H00530 Bolt
*Parts List Continued on Following Page
