Astec Mobile Screens Parts 45 KDS 710
710
KDS
ITEM QTY PART NUMBER DESCRIPTION
27 4 H00582 Screw
28 18 H00586 Bolt
29 64 H00635 Nut
30 64 H00636 Bolt
31 8 H00637 Bolt
32 1 M46050-A Rubber
33 2 M46050-BH Bearing Housing 90mm
34 2 M46050-BR Bearing Retainer
35 2 M46050-CW3 Plate
36 8 M46050-D Crown Rubber
37 9 M46050-E Crown Rubber
38 2 M46050-F Keystock
39 1 M46050-SHFT Round
40 2 M46050-SL Labyrinth Seal
41 1 M46050BD Bottom Deck Weldment
42 2 M46050CL-01L Clamp Bar Weldment
43 2 M46050CL-01R Clamp Bar Weldment
44 3 M46050CL-02 Clamp Bar Weldment
45 1 M46050MM Screen Box Motor Mount Assembly
46 1 M46050PS-L Screen Box Side Weldment
47 1 M46050PS-R Screen Box Side Weldment
48 1 M46050SB-01L Spring Bracket Weldment
49 1 M46050SB-01R Spring Bracket Weldment
50 1 M46050SB-02L Spring Bracket Weldment
51 1 M46050SB-02R Spring Bracket Weldment
52 2 M46050SB-PL07 Plate
53 1 M46050TDF Flat Top Deck Weldment
54 18 131941 Washer, Swivel
