ASTEC KDS 710 - Page 57

Astec Mobile Screens Parts 49 KDS 710
710
KDS
ITEM QTY PART NUMBER DESCRIPTION
33 16 H00078 NYLOCK
34 2 H00198 BOLT
35 4 H00434 BOLT
36 4 H00438 BOLT
37 4 H00445 BOLT
38 16 H00457 FLAT WASHER
39 8 H00463 LOCKWASHER
40 8 H00470 NUT
41 2 H00606 BOLT
42 2 H00607 BOLT
43 6 H00620 BOLT
44 2 M12050-12XE HEAVY DUTY TAKE UP
45 2 M46011C-ST-TG01 ROUND
46 1 M46011CH CONVEYOR HEAD FRAME WELDMENT
47 1 M46011CM-01 CONVEYOR MIDDLE FRAME WELDMENT
48 1 M46011CS-07 CONVEYOR SUPPORT WELDMENT #01
49 1 M46011CS-08 CONVEYOR SUPPORT WELDMENT #02
50 1 M46011CS-09 CONVEYOR SUPPORT WELDMENT #03
51 1 M46011CS-10 CONVEYOR SUPPORT WELDMENT #04
52 2 M46011CS-RT01 REC. TUBE
53 1 M46011CT CONVEYOR TAIL FRAME WELDMENT
54 1 M46011CV-TLSHFT ROUND
55 1 M46011CVAR-01L CONVEYOR ARM WELDMENT #01(LEFT)
56 1 M46011CVAR-01R CONVEYOR ARM WELDMENT #01(RIGHT)
57 2 M46011CVAR-02 CONVEYOR ARM WELDMENT #02
58 6 M46011PN-01 CONVEYOR PIN
59 1 M46111-PL11L PLATE
60 1 M46111-PL11R PLATE
61 1 M46111BRK-PL01L PLATE
62 1 M46111BRK-PL01R PLATE
63 1 M46111SHFT-TG02 ROUND
64 1 M46200PW3 PANEL WELDMENT #03
65 2 M46200PW5 PANEL WELDMENT #05
