The Aston Origin is a high-performance cardioid condenser
microphone utilising a one inch (1”) gold evaporated capsule.
It is versatile enough to use with most instruments and excels
on acoustic guitar and vocals. Its hand-selected capsule is
teamed with high-end transformer-less circuitry using only the
highest quality components.
The Origin is designed to deliver direct, smooth and intimate
sound… for a natural and transparent recording.
Specications:
Transducer Type: Condenser
Acoustic Operating Principle: Pressure Gradient
Directional Polar Pattern: Cardioid
Frequency Response: 20Hz – 20kHz (+/- 3dB)
Equivalent Noise Level: 18dB A-Weighted
Sensitivity at 1kHz into 1kohm: 23mV/Pa
Maximum SPL for THD 0.5%: 127dB
Pad Switch: -10dB/0dB
Low-Cut Filter: 80Hz
48 Volt Phantom power (+/- 4 Volts) is required for operation
6
Aston Origin
Polar Pattern
Frequency Response
