Maintenance and Technical Data
11.11
Brake Fluid Level
Warning: Do not drive the vehicle if the brake fluid level
is below the minimum mark.
Caution: Make sure that the brake fluid does not spill onto
the vehicle. The paint can be seriously damage by brake fluid.
If a spillage does occur, immediately flush any brake fluid
with clean, fresh water and then wipe with a clean damp
cloth.
The brake fluid reservoir is found under the driver's side leaf
screen in the engine bay. To check and top up the brake fluid:
1. Remove the fastener (A).
2. Remove the leaf screen panel.
3. Remove the reservoir cap. The brake fluid level should read
between the Min. and Max. marks. Top up to the Max. level
if necessary.
4. Install the reservoir cap securely.
5. Put the leaf screen panel back into position.
6. Install the fastener.
