Astralpool BX Series - Replacement Parts List

REPLACEMENT PARTS
Code Part Number Description Quantity
1 53977-78736 BX Volute 1
53976-78735 CTX Volute 1
2 53977-78106 BX Pump Lid O-ring 1
53976-70006 CTX Pump Lid O-ring 1
3 53977-40086 BX Pump Clear Lid 1
53976-40087 CTX Pump Clear Lid 1
4 53977-40068 BX Pump Lid Collar 1
53976-40088 CTX Pump Lid Collar 1
5 53977-950925 BX 2” Union Tail 2
53977-950924 BX 1.5” Union Tail 2
53976-950920 CTX Union Tail (2”) 2
53976-950918 CTX Union Tail (1.5”) 2
6 53977-950926 BX Union Lock Nut 2
53976-950919 CTX Union Lock Nut 2
7 53976-78737 CTX/BX Seal Plate 1
8 53976-70003 CTX Union O-ring 2
53976-78104 BX Union O-ring 2
10 53976-4008101 BX ( 0.75HP) CTX (1.0HP) Impeller 1
53976-4008102 BX ( 1.0HP) CTX (1.5HP) Impeller 1
53976-4008103 BX ( 1.5HP) CTX (2.0HP) Impeller 1
53976-4008104 BX ( 2.0HP) CTX (2.5HP) Impeller 1
53976-4008105 Impeller 3.0HP 1
11 53976-78720 Diuser 0.5HP - 2.5HP 1
53976-78721 Diuser 3.0HP 1
13 53977-40066 BX Pump Basket 1
53976-40065 CTX Pump Basket 1
14 53976-78104 Diuser O-ring 1
15 53976-4005002 CTX/BX Molded Motor Foot 1
16 53976-40056 CTX/BX Motor Foot Rubber Mount 1
17 53976-40111 5/16” UNC bolt HEX SS 6 and 4
18 53976-70004 CTX/BX Seal Plate O-ring 1
19 Drain Plug 2
20 Option 3” adapter 2
21 Optional Universal Base 1
22 53976-40110 3/8” UNC bolt HEX SS 4
Not Shown 53976-75508 Mechanical Seal 3/4” 1
Not Shown 53976-40165 Screw self-tap SS 2
Not Shown 53976-40112 CTX 5/16-2.25” UNC HEX SS 2
