6
Model
Electricity
supply
Max.
current
Cable diameter* Thermal magnec protecon
Eco Elyo-05
220 - 240 V
1 phase
50-60 Hz
8
RO2V 3x2,5 mm² 16 A
Eco Elyo-07
Eco Elyo-09 9
Eco Elyo-13 13
Eco Elyo-15 16
RO2V 3x4 mm²
20 A
Eco Elyo-20 19
Eco Elyo-24 21.7 25 A
Eco Elyo-30 30 RO2V 3x6 mm² 32 A
Eco Elyo-20T
380 - 400 V
3 phase
50-60 Hz
7.9
RO2V 5x2,5 mm²
10 A
Eco Elyo-24T 9.4
16 A
Eco Elyo-30T 13 RO2V 5x4 mm²
Electric supply connections
• Cut the electricity supply before any work inside the appliance (risk of electric shock). The removal of the power
supply has to be such that you can always check from any of the points to which you have access that the power
supply remains removed. If this is not possible, you should provide a disconnecon with a locking system.
• Only a qualied and experienced technician is authorised to carry out cabling work within the appliance or to
replace the power cord.
• Make sure that the terminal screws are fully ghtened (risk of re). Incorrectly ghtened terminal screws will cancel
the warranty.
• Do not disconnect the electricity supply when the appliance is running. If the electric power supply is interrupted,
wait a minute before restoring the power.
Connect the unit to the power supply and options
Heating priority connection
❶
Installaon
*Cable cross secon suitable for max. length 20 meters.
2
1 - 2: Power for the ltraon
pump power contactor coil
: ltraon mer
: power contractor (two-pole contac-
tor) for ltraon system pump motor
: separate cable for the “heang
priority” funcon (not supplied)
: heat pump terminal board
: fuse
: 230V/dry contact relay (not
included)
Open the top panel with a screwdriver (4 screws) to access the electrical terminal
block. Insert the power supply cable into one of the cable gland on the rear
part of the appliance. Inside the appliance, x the power supply cable by threading
it through the cable clamp .
Connect the power supply cable to the terminal block inside the appliance as
following.
Connect to
power supply
Connect opons
(ltraon pump,
power supply relay).
Connect
to power
supply
Connect opons
(ltraon pump,
power supply relay)
L: Live
N: Neutral
: Earth
Terminal block for single phase power supply Terminal block for tri-phase power supply
14
13
P2 P1
1
2
Cable wiring and protection
