Astro Pneumatic Tool 3036 - Parts Breakdown and Identification; Parts List and Diagrams; Contact Information for Inquiries

Call 1.800.221.9705 for questions concerning performance of the product
or other inquiries.
372 Old US Highway 52 South
Mount Airy, NC 27030
Page 4
Model:
Product Type:
3036
PARTS BREAKDOWN
Parts List
AIR BELT SANDER
(10 x 330MM)
29
28
30
27
35
26
34
25
33
32
31
24
46
45
48
50
49
43
42
44
41
40
39
38
37
36
21
22
23
15
18
14
20
17
19
13
12
16
11
10
8
7
9
3
4
2
1
5
6
51
2
45
54
3036-01
3036-02
3036-03
3036-04
3036-05
3036-06
3036-07
3036-08
3036-09
3036-10
3036-11
3036-12
3036-13
3036-14
3036-15
3036-16
3036-17
3036-18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Idle Pulley
Ball Bearing (684zz)
Idle Pulley Screw
Bracket 10
Set Screw (M3×5)
Hexagon Socket Headless Set Screw
Spring
Tension Bar
Spring Pin ( 3×10)
Stopper Pin
Guard Bushing
Tension Spring
Guard Sub Ass'y 11
Head Cap Screw (M5×15)
Dust Cover
Shoe 10
Hexagon Socket Headless Set Screw
Stopper Spring
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3036-37
3036-38
3036-39
3036-40
3036-41
3036-42
3036-43
3036-44
3036-45
3036-46
3036-48
3036-49
3036-50
30361
30362
30363
3036-54
37
38
39
40
41
42
43
44
45
46
48
49
50
51
52
53
54
Spring Pin ( 3×20)
Valve Body
O-Ring (S11.2)
O-Ring (P-9)
Valve Stem
O-Ring (P3)
Valve Spring
Air Regulator
O-Ring (P7)
External Stop Ring (STW-8)
Exhaust Diffuser
Inlet Bushing
Housing Cover
Sanding Belt 80 Grit - 10 x 330 mm
Sanding Belt 100 Grit - 10 x 330 mm
Sanding Belt 120 Grit - 10 x 330 mm
O-Ring (AS-004)
3036-19
3036-20
3036-21
3036-22
3036-23
3036-24
3036-25
3036-26
3036-27
3036-28
3036-29
3036-30
3036-31
3036-32
3036-33
3036-34
3036-35
3036-36
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
1
1
1
1
1
1
1
1
1
1
1
5
1
1
1
1
1
1
Stopper
Spring Pin ( 2.5×10)
Hexagon Nut (M6)
Washer (M6)
Drive Pulley
Housing
Ball Bearing (6000ZZ)
Front End Plate
Spacer
Rotor
Parallel Key Both Ends Round 4×4×9.5
Rotor Blade
Cylinder
Rear End Plate
Ball Bearing (608zz)
O-Ring (S38)
Cap
Throttle Lever
Index Part No. Description Qty Index Part No. Description Qty Index Part No. Description Qty
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
20140317
