Chapter 4 INTERFACE SETTINGS
97
Mode=CDC
In this mode, parameter of CDC message is edit and sent.
PASS/ FAIL criteria after CDC message transmission is different from each message. Please refer to HDMI
standard about the detail of each CDC message.
《Setting item》
(1) Target Logical Addr Set CEC Logical Address of DUT.
(This is used for result criteria when executing CDC Msg = 0, 3, 6)
Select CDC message to send
0 Inquire State <CDC_HEC_InquireState>
1 Report State <CDC_HEC_ReportState>
2 Set State Adj <CDC_HEC_SetStateAdjacent>
3 Set State <CDC_HEC_SetState>
4Req
Deactivation
<CDC_HEC_RequestDeactivation>
5 Notify Alive <CDC_HEC_NotifyAlive>
(2) CDC Msg (0-6)
6 Discover <CDC_HEC_Discover>
CDC Msg = 0 (Inquire State)
《Setting item》
(1) Dev Physical Addr1 Set Physical Address of the first Terminating Device.
(2) Dev Physical Addr2 Set Physical Address of the second Terminating Device.
《Criteria of result judgment》
If the below condition is fulfilled, the test result becomes PASS.
・ DUT (the device designated by Target Logical Addr) is included in the channel
designated by the Dev Physical Addr1 and the Dev Physical Addr2.
and
・ There is a response of <CDC_HEC_ReportState> from the DUT>.
Note : if the setting value of Target Logical Addr and the setting value of VG Logical Address are same
(DUT=VG main unit), the result is FAIL.
To Next Page
