ASTRO VG Series User Manual

190
b) Concerning the drawing mode
The following video output modes are possible using the two DisplayPort output ports.
The examples below describe the case for 1280 × 1024 resolution, a 108 MHz dot clock, with 10-bit output
level.
(1) Single mode
This is the normal output mode. The same video is output from both Port1 and Port2.
・・・・・・・
D1276
[9..0]
D1277
[9..0]
D1278
[9..0]
D1279
[9..0]
D4
[9..0]
D5
[9..0]
D6
[9..0]
D7
[9..0]
D0
[9..0]
D1
[9..0]
D2
[9..0]
D3
[9..0]
・・・・・・・
Port1
Clock
(108MHz)
Port2
・・・・・・・
D1276
[9..0]
D1277
[9..0]
D1278
[9..0]
D1279
[9..0]
D4
[9..0]
D5
[9..0]
D6
[9..0]
D7
[9..0]
D0
[9..0]
D1
[9..0]
D2
[9..0]
D3
[9..0]
(2) Dual mode
The video data is output alternately from Port1 and Port2.
・・・・・・・
D0
[9..0]
D2
[9..0]
D4
[9..0]
D6
[9..0]
D1276
[9..0]
D1278
[9..0]
D1
[9..0]
D3
[9..0]
D5
[9..0]
D7
[9..0]
D1277
[9..0]
D1279
[9..0]
・・・・・・・
・・・・・・・
Clock
(54MHz)
Port1
Port2
Port1 Port2
Port1 Port2
