ASTRO VG Series User Manual

264
2
db (1-8ch Separate)
This sets channels 1 to 8 separately as a dB
display.
Setting range: -138.48 to 0.00 [dB]
Select the level here.
3
bit (1-8ch Separate)
This sets channels 1 to 8 separately as a bit
display.
Setting range: 0 to 7FFFFFh
Select the level here.
<Int. Non L-PCM setting parameters> (Option)
Setting menu display
(1)
Flash Data No. Set the audio data here. Setting range: 1 to 99
Set the registered audio data.
* For further details on registering the audio data, refer to “4.16.3 Flash
data entry (option).”
<Int.L-PCM(Flash) setting parameters> (Option)
Setting menu display
(1)
Flash Data No. Set the audio data here. Setting range: 1 to 99
Set the registered audio data.
* For further details on registering the audio data, refer to “4.16.3 Flash
data entry (option).”
