ASTRO VG Series User Manual

558
Code (HEX) Error message Description
315 ‘Burst’ Data Error” Error in the burst pattern data.
316 ‘Window’ Data Error” Error in the window pattern data.
317 ‘Color Bar’ Data Error” Error in the color bar pattern data.
318 TERMINAL) Parameter Error Error in a parameter in the terminal mode.
319 TERMINAL) Data Error Error in the data in the terminal mode.
31B ‘Video/Setup/Sync Level’ Error
The video level (Video), setup level (Setup) and sync signal level
(Sync) are outside the setting range. (Setting range: [Video ≥ Setup]
and [Video ≥ Sync] and [Video ≥ (Setup + Sync)])
31E
TERMINAL) Communication
Timeout
Time-out has occurred in the data during communication in the
terminal mode.
31F TERMINAL) Undefined Command An undefined command was received in the terminal mode.
321 ‘Program No.’ Error” Error in the program number.
322 ‘Group No.’ Error” Error in the group number.
323 ‘Character Code’ Error” Error in a user character code.
32B ‘OPT No.’ Error” Error in the optional pattern number.
32D OPT Data File Not Found” The optional pattern has not been registered.
32E ‘Image No.’ Error” Error in the image pattern number.
330 Image Data File Not Found” The image pattern has not been registered.
333 CURSOR Not Selected
The cursor pattern has not been selected (when SP-8870 Cursor Tool
is used).
334 EDID Read Port Not Found The EDID read port is not found.
(The unit has not been installed.)
338 ‘Gray Scale’ Data Error Error in the gray scale pattern data.
339 ‘OPT/Image’ Data Error” Error in the optional pattern or image pattern data.
33B ‘Cursor’ Data Error Error in the cursor pattern data.
33C ‘Program Name’ Data Error Error in the program name data.
33D ‘×[ABC] Color’ Data Error Error in the  × [ABC] color data.
33E ‘Action’ Data Error” Error in the action data.
340 ‘V-Timing Total’ Over Limit Total in the vertical timing data is outside the setting range.
341 ‘V-Timing Disp’ Over Limit” Disp in the vertical timing data is outside the setting range.
342 ‘V-Timing Sync’ Over Limit Sync in the vertical timing data is outside the setting range.
343 ‘V-Timing Backp’ Over Limit Backp in the vertical timing data is outside the setting range.
344 ‘V-Timing Frontp’ Over Limit Frontp in the vertical timing data is outside the setting range.
345 ‘V-Timing Blanking’ Over Limit Blanking in the vertical timing data is outside the setting range.
346 V-Frequency Over Limit
The vertical sync frequency in the vertical timing data is outside the
setting range.
347 ‘V-Timing VD’ Over Limit
VDstart+VDwidth in the vertical timing data is outside the setting
range.
