ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
77
This is the LEF Playback Level setting.
0
Unknown
1
0 dB Playback
(12)
LEF PB Level
2
+10 dB Playback
 MPEG InfoFrame
If the original source of the data prior to its conversion to HDMI is MPEG data, its information is stored in MPEG
InfoFrame, and sent.
This setting determines whether the MPEG InfoFrame is to be sent.
0
OFF
The MPEG InfoFrame is not sent.
(1)
OFF/ON
1
ON
The MPEG InfoFrame is sent.
Listed below are the MPEG InfoFrame settings.
* These settings are not related to the video and audio output settings.
This is the MPEG InfoFrame type setting. (2)
Type
5
* “Type” is displayed only. It cannot be changed.
This is the MPEG InfoFrame version setting. (3)
Version
1
* “Version” is displayed only. It cannot be changed.
(4)
Bit Rate 0 - 4294 M 967 k 295 Hz
This is the MPEG bit rate setting.
This is the Field Repeat setting.
0
New Field(picture)
(5)
Field Repeat
1
Repeated Field
This is the MPEG Frame setting.
0
Unknown(No Data)
1
I Picture
2
B Picture
(6)
Frame
3
P Picture
 NTSC VBI InfoFrame
The vertical blanking interval (VBI) information is stored in NTSC VBI InfoFrame, and sent.
This setting determines whether the NTSC VBI InfoFrame is to be sent.
0
OFF
The NTSC VBI InfoFrame is not sent.
(1)
OFF/ON
1
ON
The NTSC VBI InfoFrame is sent.
Listed below are the NTSC VBI InfoFrame settings.
* These settings are not related to the video and audio output settings.
This is the NTSC VBI InfoFrame type setting. (2)
Type
6 * “Type” is displayed only. It cannot be changed.
This is the NTSC VBI InfoFrame version setting. (3)
Version
1 * “Version” is displayed only. It cannot be changed.
(4)
PES Length
0 - 27 This sets the PES length.
(5) PES 1-5/6-10/11-15/16-20/
21-25/26-27
00 - FF This sets the PES data.
