Asus 4G-N12 User Manual

27
NOTES:
• WerecommendthatyouuseanIPaddressformatof192.168.1.xxx
(where xxx can be any number between 2 and 254) when specifying
an IP address range.
• AnIPPoolStartingAddressnshouldnotbegreaterthantheIPPool
Ending Address.
6. In the Lease Time dropdown list, select the schedule when an
IP address will expire. Once it reaches this specied schedule,
the DHCP server will then assign a new IP address.
Static DHCP is a useful function, which allows you to bind specic
client device with static IP address on your LAN. The IP address on
DHCP server will be reserved for unique MAC address of a DHCP
client device based on the settings below.

Asus 4G-N12 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Rack mounting	-
xDSL connection	No
Bandwidth (first)	2.4 GHz
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	4
4G standard	LTE
3G standards	HSPA+, UMTS
4G bands supported	800, 1800, 2600 MHz
UMTS bands supported	900, 2100 MHz
Antennas quantity	2
Antenna gain level (max)	2 dBi
Security algorithms	802.1x RADIUS, WPA-PSK, WPA2-PSK, WPA2-RADIUS, WPS
Product color	Black
LED indicators	3G, Data, LAN, Power, WAN
AC input voltage	110 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	125 mm
Width	174.5 mm
Height	29.5 mm
Weight	300 g
