5-22
Chapter 5: Software support
Other feature buttons
Click
on right corner of the main window to open the monitor window
.
Click
on right corner of the expanded window to switch the temperature from
degrees Centigrade to degrees Fahrenheit.
Displays the CPU/
system temperature,
CPU/memory/PCIE
voltage, and CPU/
chassis fan speed
Displays the FSB/CPU
frequency
127
129
