Disassembly Procedure
V1.0
2 - 7
Components
The illustrations below show the components of the C423
LCD model
The illustration below shows the LCD model.
Top Case
The illustration below shows the top case.
Bottom Case
The illustration below shows the bottom case.
Thermal Module
The illustration below shows the thermal module.
C O M P O N E N T S
T O P C A S E
T H E R M AL
M O D U L E
L C D M O D E L
B O T T O M C A S E
