Asus F2A85-M PRO - AMD Option ROM Utility for RAID

ASUS F2A85-M PRO
5-3
Chapter 5
5.1.4 AMD
®
Option ROM utility
To enter the AMD
®
Option ROM utility:
1. Turn on the system.
2. During POST, press <Ctrl> + <F> to display the utility main menu.
The Main Menu allows you to select an operation to perform. The Main Menu options include:
View Drive Assignments: shows the status of the hard disk drives.
 displays the existing RAID set information / creates a RAID

Delete LD Menu: deletes a selected RAID set and partition.


The RAID BIOS setup screens shown in this section are for reference only and may not
exactly match the items on your screen.

•
•
•
•
