ix
M2N68-AM specications summary
(continued on the next page)
CPU AMD socket AM2/AM2+ for AMD Phenom™ FX /
Phenom™ / Athlon™ / Sempron™ processors
AMD64 architecture enables simultaneous 32-bit and
64-bit computing
Supports AMD Cool ‘n’ Quiet™ Technology
Chipset MCP68S/MCP68PVNT
System bus 2000 / 1600 MT/s
Memory Dual-channel memory architecture 2 x 240-pin DIMM
sockets support up to 4GB of unbufferred ECC and
non-ECC 1066 / 800 / 667 / 533 MHz DDR2 memory
modules
Notes*:
• Only AM2+ supports DDR2 1066.
• When you install total memory of 4GB or more,
Windows
®
32-bit operating system may only recognize
less than 3GB. Hence, a total installed memory of less
than 3GB is recommended if you are using a 32-bit
Windows operating system.
Expansion slots 1 x PCI Express™ x16 slot
1 x PCI Express™ x1 slot
2 x PCI slots
Graphics
Integrated Nvidia
®
GeForce
®
7 Series Shader model 3.0
DirectX9 graphics processor
Maximum shared memory of 256 MB
Supports RGB with max. resolution 1920 x 1440
(@70MHz*32bpp / 75Mhz*16bpp)
Notes*:
• Due to the chipset limitation, only MPEG 2 & WMV
Ofoad can support HD format 1920 x 1080p
• The suggested system conguration when playing HD
DVD and Blu-ray disc: DDR2 800 1GB x 2 / Althon
64 x 2 4400+ / Graphic shared memory 256 MB /
Purevideo HD support.
Storage - 1 x Ultra DMA 133 / 100 interface
- 4 x Serial ATA 3 Gb/s hard disk drives supporting
RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
congurations
- ATAPI support, AHCI mode
Supported OS Windows Vista/XP
High denition audio ALC662 High Denition Audio 6-channel CODEC
Supports Anti Pop Function
Supports S/PDIF Out interface, Jack-detect, and
multi-streaming
USB Supports up to 10 USB 2.0 / 1.1 ports (6 on the board, 4
at the rear panel)
