1-12 Chapter 1: Product introduction
3. Connect the CPU fan cable to the connector on the motherboard
labeled CPU_FAN.
Do not forget to connect the CPU fan connector! Hardware monitoring
errors can occur if you fail to plug this connector.
2. Push down two fasteners
at a time in a diagonal
sequence to secure the
heatsink and fan assembly in
place.
B
B
A
A
A
A
B
B
