P8C WS specications summary
ASUS
Unique
Features
GPU Boost with switch
ASUS Power Design
- 8+2 Phase Power Design
ASUS EPU
- EPU, EPU Switch
ASUS Exclusive Features
- MemOK!
- AI Suite II
- Anti Surge
- ASUS EFI BIOS EZ Mode featuring friendly graphics user interface
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Heat-pipe solution
- ASUS Fan Xpert
ASUS EZ DIY:
- ASUS Q-Connector
- ASUS CrashFree BIOS 3
- ASUS EZ Flash Utility
Back Panel I/O
Ports
1 x PS/2 KB/MS port
1 x S/PDIF Out (Optical and Coxial)
6 x USB 2.0/ 1.1 ports
2 x USB 3.0/ 2.0 ports
1 x IEEE 1394a
2 x Lan Connector
1 x DVI-I port
6 x Audio jacks
Internal I/O
connectors
1 x USB 3.0/2.0 connector supports additional 2 USB ports (19-pin)
1 x USB 2.0/1.1 connectors support additional 4 USB ports
2 x USB 2.0/1.1 vertical ports
24-pin ATX Power connector
8-pin ATX +12V Power connector
CPU Fan with PWM control
Chassis fan1 with Q-fan control
Chassis fan2 with Q-fan control
Chassis fan3 with Q-fan control
Power fan
AAFP connector
1 x COM port connector
1 x TPM header
1 x 1394a connector
1 x LTP1 header
S/PDIF Out header
1 x MemOK! Button
20-pin front panel connector
OS Win7 32/ 64 bit, WinXP 32/ 64 bit, Server 2003, Server 2008 and Server 2008
R2
Form factor ATX Form Factor, 12in x 9.6in (30.5cm x 24.5cm)
*Specications are subject to change without notice.

Asus P8C WS Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® C216
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Server 2008 R2 Enterprise Windows Server 2008 Enterprise 32/64-bit Windows Server 2003 R2 Enterprise 32/64-bit Windows 7 32/64-bit Windows XP 32/64-bit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16, 2x4, 2x8
PCI Express slots quantity	5
LAN controller	Intel® 82574L
Networking features	2 x Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	245 mm
Width	305 mm
