Asus P8H61 USB3 R2.0 User Manual

ix
P8H61 R2.0 Series specications summary
Special features 100% All High-quality Conductive Polymer Capacitors
(P8H61/USB3 R2.0 and P8H61 PLUS R2.0 only)
ASUS unique features ASUS DIGI+ VRM:
- Digital Power Control: Digital Power Design for the CPU
- ASUS 3+1 Phase Power Design
ASUS Exclusive Features:
- Network iControl* featuring instant network bandwidth
domination for top network program in use
- USB 3.0 Boost featuring the latest USB 3.0 UASP standard
(P8H61/USB3 R2.0 only)
- Disk Unlocker featuring 3TB+ HDD support
- ASUS Anti-Surge Protection
- ASUS EPU
- ASUS TurboV
- ASUS AI Charger+ (P8H61/USB3 R2.0 only)
- ASUS AI Charger
- ASUS AI Suite II
- ASUS Low EMI
- ASUS ESD
ASUS Quiet Thermal Solution:
- ASUS Fan Xpert
- ASUS Fanless Design: Stylish Heatsink solution
ASUS EZ DIY:
- ASUS UEFI BIOS featuring friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2™
* The Network iControl feature does not support Windows
®
XP/Vista operating systems.
ASUS exclusive
overclocking features
Precision Tweaker:
- vCore: Adjustable CPU voltage at 0.005V increment
- vCCSA: 190-step system agent voltage control
- vDRAM Bus: 190-step Memory voltage control
- vPCH: 190-step Chipset voltage control
SFS (Stepless Frequency Selection):
- BCLK/PCIE frequency tuning from 80MHz up to 300MHz at
1MHz increment
Overclocking protection:
- ASUS C.P.R. (CPU Parameter Recall)
(continued on the next page)

Asus P8H61 USB3 R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 2000, 2133, 2200 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA, SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Cables included	SATA
Special features	2 x Thunderbolt
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	198.1 mm
Width	305 mm
