ASUS Q170T

1-5

WhenusingPCIcardsonsharedslots,ensurethatthedriverssupport“ShareIRQ”orthat

thecardsdonotneedIRQassignments.Otherwise,conictswillarisebetweenthetwoPCI

groups,makingthesystemunstableandthecardinoperable.

IRQ assignments for this motherboard

A B C D E F G H

HDAudiocontroller shared – – – – – – –

XHCI shared – – – – – – –

SATAcontroller shared – – – – – – –

RealtekLANcontroller – shared – – – – – –

IntelLANcontroller shared – – – – – – –

M.2 shared – – – – – – –

IGD shared – – – – – – –

WLAN – – – shared – – – –

RTC Battery header (2-pin BATT_CON)

ThisconnectorisforthelithiumCMOSbattery.

M.2 WIFI

ThissocketconnectstoanM.2WI-FIdevice.Usethebundledscrew3020-

01810100tosecureyourM.2device.

Serial port connector (10-1 pin COM)

Connecttheserialportmodulecabletothisconnector,theninstallthemoduletoa

slotopeningatthebackofthesystemchassis.
