Asus Q170T User Manual

viii
Q170T specications summary
Rear panel
I/O ports
1 x DC power connector*
1 x HDMI port
1 x DisplayPort
2 x LAN (RJ-45) ports
4 x USB 3.0/2.0 ports
2 x Audio jacks
* Connector dimension: 7.4 x 5.1mm, support both 19V and 12V DC input
Internal
connectors/
switches/
buttons
1 x USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
2 x USB 2.0/1.1 2-port connectors support additional 4 USB 2.0/1.1 ports
1 x USB 2.0/1.1 1-port connector
1 x eDP connector
1 x LVDS connector
1 x eDP/LVDS switch jumper
1 x COM connector
1 x Chassis intrusion header
1 x SATA power connector
4 x SATA 6.0 Gb/s connector
1 x CPU fan connector
1 x Chassis fan connector
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x Speaker connector
1 x DIS ME jumper
1 x Clear CMOS header
Connectors for AIO System
1 x 2-pin internal DC power connector
1 x Stereo speaker connector
1 x DMIC header
1 x Custom solutions header
Connectors for Flat Panel Display
1 x Backlight inverter voltage selection header
1 x Flat panel display brightness header
1 x Panel voltage selection header
1 x Panel off header
TPM 2.0 IC Onboard
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI
5.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F3 My Favorites,
Quick Note, Last Modied log, F12 PrintScreen, and ASUS DRAM SPD (Serial
Presence Detect) memory information, F6 Qfan Control
Manageability
WfM 2.0, DMI 3.0, WOL by PME, WOR by PME, PXE
Support DVD
Drivers
ASUS utilities
ASUS Update
Anti-virus software (OEM version)
(continued on the next page)

Asus Q170T Specifications

General

Brand	Asus
Model	Q170T
Category	Motherboard
Language	English
