Notebook PC E-Manual
Mini DisplayPort
This port allows you to connect your Notebook PC to an
external display.
HDMI port
This port is for the HDMI (High-Denition Multimedia Interface)
connector and is HDCP compliant for HD DVD, Blu-ray, and
other protected content playback.
USB Type-C/Thunderbolt 3 combo port
The USB 3.1 (Universal Serial Bus 3.1) port provides a transfer
rate up to 10 Gbit/s and is backward compatible to USB 2.0.
Use a Thunderbolt 3 adapter to connect your Notebook PC to a
DisplayPort, VGA, DVI, or HDMI external display and experience
high-resolution display features via Intel® Thunderbolt™
technology.
NOTE: Transfer rate of this port may vary per model.
USB 3.0 port
The USB 3.0 (Universal Serial Bus 3.0) port provides a transfer
rate up to 5 Gbit/s and is backward compatible to USB 2.0.
Headphone/Headset/Microphone jack
This port allows you to connect amplied speakers or
headphones. You can also use this port to connect your headset
or an external microphone.
