Asus ROG STRIX Z690-E GAMING WIFI - Front I;O connector

ROG STRIX Z690-E GAMING WIFI
2-17
Chapter 2
2.1.8 Front I/O connector
USB 3.2 Gen 2x2 Type-C
®
To install USB 3.2 Gen 2x2 Type-C®
connector
To install the front panel connector
This connector will only fit in one
orientation. Push the connector until it
clicks into place.
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector
USB 3.2 Gen 1
To install USB 3.2 Gen 1 connector
