1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
causeyouphysicalinjuryanddamagemotherboardcomponents.
Slot No. Slot Description
1 PCIe3.0x16_1slot
2 PCIe2.0x1_1slot
3 PCIe2.0x16_2slot
4 PCIe2.0x1_2slot
5 PCIe2.0x1_3slot
®
PCIEX1_1
PCIEX1_2
PCIEX1_3
PCIEX16_1
PCIEX16_2
