Asus VG27AH - Detaching the Arm (for VESA Wall Mount)

2-3
Chapter 2: Setup
2.3 Detaching the arm (for VESA wall
mount)
The detachable arm of this monitor is specially designed for VESA wall
mount.
To detach the arm:
1. Disconnect power and signal cables.
2. Lower the monitor to its lowest height, and then insert the height
adjustment lock.
3. Carefully putthefrontofthemonitorfacedownonaatandclean
table.
4. Use a screwdriver to remove the four screwdrivers on the arm (Figure
1), and then detach the arm from the monitor (Figure 2).
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the stand while removing the screws.
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load 28 kg
(Screw size: M4 x 12 mm).
