EN 11
INSTALLATION
Connection
Electric connection
• The appliance has been manufactured as a class I.
• This appliance is fitted with an earthed plug, which should
be connected to an earthed wall socket.
Check that the voltage indicated on the rating plate matches the
voltage of your household supply.
The appliance should be connected to the mains as follows:
• BROWN = L live
• BLUE = N neutral
• GREEN/YELLOW = earth
This canopy hood has been provided with a power plug.
When installing the hood, make sure that this plug remains
accessible. We recommend installing the wall socket out of view,
behind the chimney cover.
Attention!
If you are making a fixed connection, you must ensure that a double
pole switch with an air gap of at least 3 mm is fitted in the supply line.
max 130 cm
