Assembly Instructions
Step 1:
Step 2:
Step 3:
Diagram 1 Diagram 2 Diagram 3
One-Year Warranty:
ITEM# ORDERING PART# PART DESCRIPTION QTY
1 PRT81055-02 Leg A 1
2 PRT81055-02 Leg B 1
3 PRT81055-01 O-Rinq Tube 1
4 PRT81055-04 Swivel Mount Plate 1
PRT81055-05 Seat Pad Checker - AG05964G
PRT81056-05 Seat Pad Flame - AG05962G
6 PRT81055-H Screw, M6 x 45 4
7 PRT81055-H Nylon Locking Nut 4
8 PRT81055-H Screw, M6 x 20 8
9 PRT81055-03 Rubber Cap 4
5 1
