10. BOM (Parts List)
- Main Board
Location Number
No Part number Parts Name Specification QTY
1 2 3 4 5 6 7 8 9 10
1 VMT-0072AB PWB(PCB) ASSY,MAIN VCB4430 MAIN TOTAL
1
VMH-0072AB
PWB(PCB) ASSY,MAIN VCB4430 MAIN
HAND INSERTING
1 BOARD LABEL VCB4450
1 JACK AUDIO PHONE JACK 3.5PIE
NINENEW SJ3501-5 H7
2 J44 J902
2 D-SUB 15F- BLUE DSH03A-15F-BU 15P D-SUB
2.29MM FEMALE RIGHT ANGLE
(육각 5.85mm 결합형)
1 J903
3 AV-JACK
J/B 9P+DIN(RCA/Mini-Din 일체형)
1 J11
4 SCART JACK RC103 SCART JACK21P 2 J905 J907
5 WAFER SMW250-12 12P YEON-HO
2.5mm STRAIGHT
1 J701
6 WAFER SMW200-2 2P YEON-HO
2.0mm STRAIGHT
2 J41 J42
7 WAFER SMW200-3 3P YEON-HO
2.0mm STRAIGHT
2 J912 J915
8 WAFER SMW200-4 4P YEON-HO
2.0mm STRAIGHT
1 J909
9 WAFER SMW200-5 5P YEON-HO
2.0mm STRAIGHT
1 J45
10 WAFER SMW200-10 10P YEON-HO
2.0mm STRAIGHT
1 J33
11 TUNER TECH2949PG40B-PAL SAMSUNG 1 U639
12 SAW FILTER,EPCOS X6966M-M100 IF filter for
digital cable TV (PAL 용)
1 U603
13 AXIAL,INDUCTOR AL04TB-122K 1.2mH//44MA
5.0MM==아비코
1 L602
14 AXIAL,INDUCTOR AL02TB-R33K 3.3UH//44MA
5.0MM==아비코
1 L601
15 Al. CAPCITOR/SAMYOUNG 470UF 16V M 8*11.5*5.0 SH
L-TYPE
3 C534 C603 C732
16 Al. CAPCITOR/SAMYOUNG 220UF 16V M 6.3*11*2.5 SH
L-TYPE
8 C536 C537 C626 C723 C724 C725 C726 C738
C535 C553 C712 C714 C716 C717 C785 C786 C791 C793 17 Al. CAPCITOR/SAMYOUNG 100UF 16V M 5*11*2.5
SHL -TYPE
12
C934 C935
To Next Page
