WWW.ATKBINDINGS.COM | PROUDLY MADE IN ITALY SINCE 2007 31
3.2.3| ADJUSTMENT: HOW TO ADJUST THE “U.H.V.” SYSTEM
The “U.H.V” system provides a locking hardness variation to perfectly fit with the different styles of boots
inserts and user’s needs. By adjusting the selector in “Soft”, “Mid” or “Hard” position, the force needed to
lock the front lever will increase or decrease. At the same time, the pins locking pressure on the boot insert
will increase or decrease.
WARNING! DANGER!
Hook the boot at the binding and
set it for the uphill walking mode.
Rotate the boot on the toe up to
the front end of the rotation-
range and verify that the boot is
performing at least a 90° free
rotation.
If the free rotation range is smaller
than 90°, the boot tip and/or the
front part of the binding could be
damaged by a regular use of the
set.
BOOT FREE
ROTATION
RANGE >= 90°
